Plastic PVC roof panel extruder

PVC Wave Roofing Sheet/Tile Production LineASA/PMMA + PVC for Glazed TileASA/PMMA + PVC for Roof TileASA/PMMA + PVC+PVC for Roof TilePVC Three-Layer Foaming Roof TilePVC Common Roof Tile/Transparent Roof tilePVC PC wave sheet applacations:1, garden, agricultural greenhouse and indoor fish greenhouse sunroof, cellar, arched roof

Featured Products

PVC Wave Roofing Sheet/Tile Production Line
  1. ASA/PMMA + PVC for Glazed Tile
  2. ASA/PMMA + PVC for Roof Tile
  3. ASA/PMMA + PVC+PVC for Roof Tile
  4. PVC Three-Layer Foaming Roof Tile
  5. PVC Common Roof Tile/Transparent Roof tile
Plastic PVC Roof Sheet Extrusion Making Machine
PVC PC wave sheet applacations:

1, garden, agricultural greenhouse and indoor fish greenhouse sunroof, cellar, arched roof and commercial greenhouses;
2, modern railway station, airport waiting hall and channel ceiling;
3, modern bus station ferry terminal and other public facilities cover;
4, plant, warehouse, market and other areas of lighting;


PVC PC wave sheet features:

1, translucent.
2, weatherability.
3, impact resistance.
4, with flame retardant
5, temperature resistance.
6, portable.


PVC PC wave sheet Materials:
The formulation usually consists of PVC Resin, Lubricant, Caco3, Stabilizing Agent, Pigment, Anti-ultraviolet Agent and Other Additives.


Equipment list:
1 Extruder: You can have one, two or three extruders to make the different layer roof sheet
2 T-die and distributor
3 Shaping mould, rubber roller, cutter
4 Stacker



Technical Parameters:

StructureSingle layerDouble layersTriple layersTriple layers
MaterialPVCASA/PMMA
+PVC
ASA/PMMA
+PVC+PVC
PVC+PVC foaming +PVC
Width720-1130mm720-1130mm720-1130mm720-1130mm
Thickness0.8-3.0mm1.5-3.0mm2.0-3.0mm2.0-3.0mm
Extruder
 Model
SJZ80/156SJ50/30
+SJZ80/156
SJ50/30
+SJZ65/132
+SJZ51/105
SJZ51/105
+SJZ65/132
+SJZ51/105
Designed Output300kg/h330-350kg/h330-350kg/h330-350kg/h
