KQ8-128 (KQ8-180) roof tile machine basic introduction

    KQ8-128 (180)roof tile machine is a new and popular equipment in modern society for making cement and  concrete color roof tiles. KQ8-128 roof tile machine adopts advanced technology like PLC combine hydraulic
press. This roof tile making machine has better mechanism capability and economic benefit.KQ8-128 roof tile
machine is widely used in building and ancient architecture,etc.

(1). Fast forming speed,high production. Four-Post Type Tile Making Machine features PLC automatic control, host machine interface and dependable  performance.
(2). After the mortar is mixing-rolled,the concrete tiles fabricated features is perfect, various style,high density, high intensity and accurate size, so that the concrete roof tiles can meet the needs of different constructions.KQ8-128 concrete roof tiles are best among concrete products
(3).The KQ8-128 roof tile making machine can be used for muti usage.By changing roof tile moulds, the equipment can produce various styles of main roman roof tiles,double roman roof tiles,ridge tiles,edge tiles and ditch tiles.Also KQ125 roof tile machine can produce different styles of high grade concrete roof tiles,floor tiles and paver bricks.



Main technical parameters


NoModelKQ8-128(KQ8-180)Remark
1Overall Dimension3300×1600×2480 mminstalled
2Moulding Cycle8-10 s/  6-9pcs/min
3Moulding Pressure128-180Ton
4Weight of Main machine5TMain machine
5Equipped power7.5 kw
6Mixer power5.5KW
7Production Capacity3000-4000 pcs/day
8Main Tile Size420×330 mmCustomized
9Working power Hydraulic pressureNo vibration
10Operate workers 3-4 people
11Mould type CNC making Automatic


The Consist of roof tile machine:

1Main roof  tile making machine1 set
2Constant feeder machine/Quantitative feeder machine1 set
3Mixer for concrete roof tile1 set
4Elevator with bucket1 set
5Mould for concrete roof tile1 set
6Pallets for concrete roof tile2000 pcs
7Concrete roof tile painting machine1 set
8Air comprssor1 set
