Thickness | 0.15mm-0.9mm | ||||
Width | 660~1100mm | ||||
Length | 1000-11800mm | ||||
Grade | DX51D+Z DX52D+Z DX53D+Z DX54D+Z DX56D+Z DX57D+Z | CS A CS B CS C FS A FS B | SGCC SGCD | SGC340 SGC400 SGC440 SGC490 SGC510 | S220GD+Z S250GD+Z S280GD+Z S320GD+Z S350GD+Z S550GD+Z |
Zn Coating | Z30-Z275 | ||||
Color | According to RAL code | ||||
Coating Types | PE, SMP, JD, HDP, PVDF | ||||
Coating | Top Paint: 10~25 micron | ||||
Back Paint: 5~12micron | |||||
Type of coating process | Front: Double Coated & Double Drying | ||||
Back: Double Coated & Double Drying, Single Coated & Double Drying | |||||
Finish | High light, Glossy, Matte | ||||
Packing | Standard export package (Plastic film in the first layer, second layer is Kraft paper. Third layer is galvanized sheet+package strip+corner protected, one pallet about 3 tons) | ||||
Application | Building industry ,structural use, roofing, commercial use ,household appliance, industry facilities, office buildings | ||||
Advantages | 1.Design according to customers 'requirements 2.Production under ISO9001-2008 Quality System 3.Easy to be installed as light weight 4.Our products are recyclable materials 5.The less construction period, the more using time.6.paint your logo for fre |
